Item ID: 253848
Product Code: Toyota 2GR
Serial Number: K3627 2GR 0648592X
Year: 2007-2016
Mileage: 60,000 miles
Applications:

2009-2016 Toyota Venza Engine ONLY
2011-2006 Toyota Sienna FWD
2007-2011 Lexus RX350 FWD
2007-2011 Camry V6 FWD
2007-2011 Avalon FWD
2005-2012 RAV4 V6 FWD

What is a Toyota 2GR-FE engine?

The 2GR-FE is Toyota’s 3.5L DOHC V6 gasoline engine used in numerous Toyota and Lexus vehicles. This particular JDM unit uses the no-external-oil-cooler configuration and targets compatible replacement applications.

What vehicles can this 2GR-FE fit?

Your current listing identifies applications including select Toyota Venza, Sienna, Camry V6, Avalon, RAV4 V6 and Lexus RX350 models. Because 2GR-FE configurations vary by model, year and drivetrain, customers should verify the VIN and original engine before ordering.

Does this 2GR-FE have an engine oil cooler?

No. This specific engine does not have the external engine oil cooler. Your live listing explicitly identifies it as the no-oil-cooler version.

If the customer’s original 2GR-FE uses an oil-cooler configuration, verify compatibility before purchase rather than assuming interchangeability.

Has this 2GR-FE been compression tested?

Yes. J-Spec Auto currently lists 210 PSI engine compression and provides a test video for 2GR 0648592 / K3627.

Cylinder 1: 200 PSI
Cylinder 2: 200 PSI
Cylinder 3: 200 PSI
Cylinder 4: 200 PSI
Cylinder 5: 200 PSI
Cylinder 6: 200 PSI

Does the Toyota 2GR-FE use a timing belt or timing chain?

The 2GR-FE uses a timing-chain system. Therefore, there is no conventional timing-belt replacement interval. Nevertheless, inspect the timing chains, guides, tensioners and related components before installation.

What gaskets and seals should I replace before installation?

Inspect and replace appropriate accessible components, including:

• Valve-cover gaskets
• Front crankshaft seal
• Rear main seal as appropriate
• Intake manifold gaskets
• Exhaust gaskets
• Other accessible O-rings and seals

Completing this work while the engine remains outside the vehicle can reduce future labor.

Should I replace the spark plugs and ignition components?

Yes. Install appropriate new spark plugs and inspect the ignition coils, connectors and wiring before initial startup.

Should I inspect the water pump and thermostat?

Yes. Inspect the water pump, thermostat and related cooling-system components while the engine remains outside the vehicle. Replace components as appropriate based on condition and service history.

Should I inspect the timing components?

Yes. Inspect the timing chains, guides and tensioners before installation. Address worn or questionable components while access is easier.

How should I prime the 2GR-FE before startup?

Do not immediately start the replacement engine after installation.

First, install a new oil filter and fill the engine with the correct oil. Next, disable fuel and ignition according to the appropriate Toyota service procedure.

Crank the engine in controlled intervals to establish lubrication before normal startup. Once proper lubrication has been confirmed, restore the required systems and proceed with initial startup.

How should I bleed the 2GR-FE cooling system?

Fill the cooling system with the correct Toyota-compatible coolant according to the applicable service procedure. Next, thoroughly purge trapped air while monitoring coolant level, circulation and engine temperature.

Verify heater operation and radiator-fan operation during the initial heat cycle. After complete cooldown, recheck coolant level and inspect for leaks.

Do not consider the installation complete until the cooling system is thoroughly bled and maintains a stable operating temperature.

What should I check during first startup?

Monitor engine lubrication, coolant temperature, coolant circulation, oil leaks, coolant leaks, fuel leaks, abnormal noises, misfires, warning lights and radiator-fan operation.

Finally, scan the ECU for diagnostic trouble codes and recheck all fluid levels after complete cooldown.

Recommended Installation Checklist

1. Verify the JDM 2GR-FE against the original engine.
2. Confirm that the original application uses the appropriate no-oil-cooler configuration.
3. Verify VIN, year and drivetrain.
4. Transfer required vehicle-specific components.
5. Replace appropriate accessible gaskets and seals.
6. Inspect the timing chains, guides and tensioners.
7. Inspect the water pump and thermostat.
8. Install appropriate new spark plugs.
9. Inspect ignition coils and wiring.
10. Inspect PCV components.
11. Install fresh engine oil and a new oil filter.
12. Prime the lubrication system before startup.
13. Fill and thoroughly bleed the cooling system.
14. Confirm proper coolant circulation.
15. Verify stable operating temperature.
16. Check for oil, coolant and fuel leaks.
17. Scan the ECU for diagnostic trouble codes.
18. Recheck oil and coolant after complete cooldown.

Always follow applicable Toyota factory service procedures and J-Spec Auto Sports warranty requirements.
